| Shank Height (H) | 23 mm | Minimum Bore Diameter (DMIN) | 26.8 mm |
| Cutting Width (CW) | 6 mm | Tool Type | Face Turning & grooving Tools |
| Cutting Direction (HAND) | Right Hand | Body Material | Steel |
| Overall Length (OAL) | 200 mm | Functional Width (WF) | 13.3 mm |
| Connection Diameter Machine Side (DCONMS) | 25 mm | Measurement Type | Metric |
| Application | | Face grooving | | Unit | M |
| Head Length (LH) | 38.5 mm |
Product Features
| Family Description | Toolholders for face / internal face grooving & turning | FamilyName | CTIFR/L |
| Remarks | See applicable inserts table. Use the right hand insert for the right hand holder with DTF insert. Torque: Recommended torque (Nm) for clamping | BrandName | Tungaloy |
| COO | SOUTH KOREA |
Shipping Info
Weight per item
0.6700
Name
Face Groove/Turn Indexable Holders
FamilyName
CTIFR/L
BrandName
Tungaloy
