EXLS02U0.50C0.50LH2.00R02
High feed milling endmills with LSMT inserts
| Cutting Diameter (DC/DCX) | 0.354″ | Head Length (LH) | 2″ |
| Cutting Diameter (DC) | 0.354″ | Functional Length (LF) | 4-1/4″ |
| Cutting Item Count (CICT) | 2 | Tool Type | CUTTER - SHANK TYPE |
| Depth of Cut Maximum (APMX) | 0.019″ | Tool Cutting Edge Angle (KAPR) | 12 Degrees |
| Overall Length (OAL) | 4-1/4″ | Measurement Type | Inch |
| Shank Type | Round | Body Material | Steel |
| Application | | High Feed Milling | Profile Milling | | Cutting Diameter Maximum (DCX) | 1/2″ |
| Connection Diameter Machine Side (DCONMS) | 1/2″ | Unit | I |
| Master Insert Identification (MIID) | LSMT0202ZER-HM |
Product Features
| Family Description | High feed milling endmills with LSMT inserts | FamilyName | EXLS |
| COO | JAPAN | BrandName | Tungaloy |
Shipping Info
Weight per item
0.0000
Name
Indexable End Mills
FamilyName
EXLS
BrandName
Tungaloy
