| Cutting Diameter (DC/DCX) | 34 mm | Functional Length (LF) | 130 mm |
| Cutting Item Count (CICT) | 2 | Tool Type | 90 indexable endmills |
| Depth of Cut Maximum (APMX) | 8 mm | Tool Cutting Edge Angle (KAPR) | 91 Degrees |
| Overall Length (OAL) | 130 mm | Measurement Type | Metric |
| Application | | Multi Functional tools | | Body Material | Steel |
| Connection Diameter Machine Side (DCONMS) | 32 mm | Shank Length (LS) | 59 mm |
| Master Insert Identification (MIID) | SPMM322ER-CG | Cutting Diameter Maximum (DCX) | 34 mm |
| Head Length (LH) | 71 mm | Unit | M |
Product Features
| Family Description | Indexable counter boring endmill cartridge type | FamilyName | TCB cartridge type |
| Remarks | The cartridge sets and shim plates are included. | BrandName | Tungaloy |
| COO | JAPAN |
Shipping Info
Weight per item
0.0000
Name
Indexable End Mills
FamilyName
TCB cartridge type
BrandName
Tungaloy
