RCMT1204FN-NAJ KS15F
Insert for RoundSplit cutters with lapped surface and serated edge for aluminum machining
| Applicable Material | | Aluminum / Non-Ferrous Materials | Super-Alloys / Titanium | | Maximum Feed per Tooth (fz(max)) | 0.25 mm/tooth |
| Application | | Profile Milling | | Cutting Edge Material | Carbide |
| Corner Radius (RE) | 6 mm | Tool Type | Single sided Inserts |
| Depth of Cut Maximum (APMX) | 6 mm | Minimum Feed per Tooth (fz(min)) | 0.17 mm/tooth |
| Inscribed Circle Diameter (IC) | 12 mm | Number of Cutting Edges | 4 |
| Insert Thickness (S) | 4.8 mm | Measurement Type | Metric |
| Coating | Uncoated | Body Material | Carbide |
| Grade | KS15F | Unit | M |
Product Features
| Family Description | Insert for RoundSplit cutters with lapped surface and serated edge for aluminum machining | FamilyName | RCMT-NAJ |
| COO | GERMANY | BrandName | Tungaloy |
Shipping Info
Weight per item
0.0530
Name
Milling Indexable Inserts
FamilyName
RCMT-NAJ
BrandName
Tungaloy
