VDI40C2C3A-402585-JHPMC
Axially oriented VDI adapters for square shank left-hand toolholders with hose-free direct coolant supply. Clamping screw on top, parallel clamping.
| Shank Height (H) | 25 mm | Application | | Straight shape | |
| Shank Width (B) | 25 mm | Body Material | Steel |
| Functional Length (LF) | 21 mm | Tool Type | VDI-DIN69880 |
| Connection Diameter Machine Side (DCONMS) | 40 mm | Measurement Type | Metric |
| Cutting Direction (HAND) | Left Hand | Unit | M |
Product Features
| Family Description | Axially oriented VDI adapters for square shank left-hand toolholders with hose-free direct coolant supply. Clamping screw on top, parallel clamping. | FamilyName | VDI-C2/C3A-JHPMC |
| Remarks | Applicable for 8 MPa pressure coolant | BrandName | Tungaloy |
| COO | CHINA |
Shipping Info
Weight per item
0.0000
Name
Groove/Turn Indexable Holders
FamilyName
VDI-C2/C3A-JHPMC
BrandName
Tungaloy
