| Cutting Width (CW) | 1.5 mm | Cutting Edge Angle Major Left Hand (PSIRL) | 0 Degrees |
| Insert Thickness (S) | 3.5 mm | Work Piece Parting Diameter Maximum (CUTDIA) | 14.5 mm |
| Insert Length (INSL) | 25 mm | Measurement Type | Metric |
| Cutting Edge Material | Carbide | Body Material | Carbide |
| Coating | TiN | Cutting Edge Angle Major Right Hand (PSIRR) | 16 Degrees |
| Grade | ZM3 | Unit | M |
| Application | | Inserts for miniature | |
Product Features
| COO | Japan | BrandName | NTK Cutting Tools |
| FamilyName | CTPA type insert |
Shipping Info
Weight per item
0.0081
Name
Parting Off Indexable Inserts
FamilyName
CTPA type insert
BrandName
NTK Cutting Tools
